3D Effect Puff Photoluminescent Heat Transfer Vinyl

Give your designs depth and light. EVERYGLOW® 3D Puff Photoluminescent HTV creates a raised, tactile effect that glows for 10+ hours. The perfect choice for premium hoodies, caps, and custom apparel.

3d-puff-photoluminescent-htv Transform flat designs into embossed 3D graphics that shine in the dark. EVERYGLOW® Puff Glow HTV offers a soft, foam-like expansion and professional-grade photoluminescence. Hot-peel for maximum volume and long-lasting durability through repeated washes.

Description: 3D Effect Puff Photoluminescent Heat Transfer Vinyl (HTV)

1. Overview

The EVERYGLOW® 3D Effect Puff Photoluminescent Heat Transfer Vinyl (HTV) represents the next generation of garment decoration technology. This innovative glow in the dark heat transfer film combines a dramatic dimensional “puff” expansion with advanced photoluminescent pigments. Upon heat application, the vinyl expands to create a raised, 3D texture that stands out from the fabric, providing a tactile experience while emitting a brilliant, sustained glow in total darkness.

The Photoluminescent heat transfer vinyl material is specifically designed for high-end streetwear, fan merchandise, and creative apparel designers who want to combine structural depth with luminous visibility.

2. Key Features

Dimensional Expansion: The film “puffs” up when heat-pressed, transforming flat designs into embossed-style 3D graphics.
High-Intensity Afterglow: Loaded with premium strontium aluminate crystals, providing 8–10+ hours of visible glow (available in Neon Green and Aqua Blue).
Unique Tactile Feel: Offers a soft, foam-like raised surface that is lightweight and flexible on the garment.
High Contrast Visibility: The 3D profile catches ambient light from various angles, enhancing both the daytime shadow-effect and the nighttime glow.
Superior Adhesion: Engineered to bond securely with cotton, polyester, and blended fabrics, maintaining its 3D shape through repeated wear.

3. Technical Specifications

Property	Typical Value
Material Base	Expanding Polyurethane (PU) with Photoluminescent material
Initial Thickness	130–150 microns (before puffing)
Finished Thickness	Up to 500+ microns (after heat expansion)
Glow Duration	Class B/C Performance (8–12 Hours)
Standard Colors	Natural White (Glows Green) / Aqua White (Glows Blue)
Carrier	Non-Sticky / Pressure Sensitive Polyester Liner

4. Application Instructions (CRITICAL)

To achieve the perfect “puff” effect and ensure the glow performance is maintained, follow these specific parameters:

Cut Profile: Cut in Reverse (Mirror Image). Ensure blade depth is sufficient for the slightly thicker initial film.
Temperature: 145°C – 155°C (290°F – 310°F). Note: Too much heat can “collapse” the puff.
Pressure: Firm Pressure is required to ensure the expansion happens uniformly.
Time: 8–12 seconds.
Peel: HOT PEEL. Remove the carrier immediately after the press opens to allow the material to expand freely without restriction.

5. Primary Applications

Streetwear Branding: Raised, glowing logos on oversized hoodies and t-shirts.
Fan Merchandise: Concert and event apparel where the 3D texture adds a premium “retail” look.
Creative Typography: Making text and slogans pop off the fabric with both physical height and light.
Outerwear: Adding luminous, dimensional accents to caps, bags, and jacket backs.

6. Care & Maintenance

Wash Inside Out: Always wash the garment inside out to protect the 3D raised surface from abrasion.
Temperature: Machine wash cold or warm.
Drying: Tumble dry on low or hang dry. Do not use high-heat drying cycles.
Ironing: DO NOT IRON directly on the puffed vinyl. The heat from a household iron will flatten the 3D effect permanently. Iron from the reverse side if necessary.
