LB-OR Luminous pigment orange-red color

  • >>Everyglow LB-OR 30~45um
  • >>Non-toxic
  • >>Harmless
  • >>Eco-friendly
  • >>Free of radioactive
  • >>Long afterglow time
  • >>Super High brightness

Description

Everyglow LB Colorful Series luminescent pigment is from colorless base photoluminescent pigment LBG yellow-green coating with fluorescent color pigment,to gain the wonderful daylight pigment. Everyglow LB-OR luminescent pigment available glow exceed 8~12hours just absorb the visible light for 5-30mins, and this emit & absorb light process is repeatedly,no power request.

Products Properties:

Free of  radioactive elements , non-toxic, harmless, Eco-friendly material.

Longer afterglow time and super higher luminance than traditional ZnC sulphur luminecent material.

Perfect light resistance. under 300W high pressure mercury lamp for 1000hr even not reduce them luminance.

High chemicals stability. Everyglow PL pigment not reaction with any organic and inorganic agents except mercury.

Long life time.  as long as 30 years life time.



Series LB-OR  D50= 38um
Chemical composition SrAlxOy:Eu2+,Dy3+ Appearance Orange Red
Average Dimater 30~45μm Glow color Orange
Specific gravity 3.6 Exciting wavelength(nm) 200~450nm
MOH’s Hardness 6.2~6.5 Emission wavelength 520Nm
Hydrous content <0.05% Afterglow luminance mcd/m2 >450mcd/m2 at        10mins
PH (in Water) 10~11 >45mcd/m2 at 60mins

Note: Test standard: DIN67510 Part 1

1) Excited by light source D65 1000Lx for 10mins;

2)The afterglow time indicates the time during which the pigment decline to 0.32 mcd/m2

3) The error about ± 10% is allowed in above data.

4) Color: G-yellow-green , B-aqua , Y-yellow, P-purple,O-orange

Package:

1kg/bag, 25kg/drum, 500kg/pallet.

Application:

These pigment is mainly applicable as an additive in the paints, coating, ink, plastics, and other transparent medium to realize it self-luminescent function.(Suggest glow paint,ink,plastic,silicon).

Everyglow LB-OR orange red daylight color

Everyglow LB-OR orange red daylight color

Everyglow LB-OR orange luminescent in dark

Everyglow LB-OR orange luminescent in dark
